Hydrostatic pressure & bursting testing machine pipe diameter range
Φ8-1800mm PPR PB PERT PE PVC
Applications:
This hydrostatic pressure testing machine is suitable for a wide
range of product application occasions and scenarios. It is
commonly used in the testing of thermoplastic pipes used in water
supply and drainage systems, heating systems, and other industrial
applications. This machine is especially useful in the construction
industry for ensuring the quality and safety of pipes used in
buildings and infrastructure..
Product Description:
This Hydrostatic Pressure Testing Machine comes with an
overpressure and over-temperature safety protection feature, which
ensures that the machine is safe to use. The overpressure safety
protection feature automatically cuts off the water supply when the
pressure exceeds the set value, while the over-temperature safety
protection feature automatically cuts off the heating power supply
when the temperature exceeds the set value.
This Hydrostatic Pressure Testing Machine is certified by CE and
ISO, ensuring its quality and reliability. With an accuracy of
-1%~+2%, this testing machine provides precise and consistent
results. The testing range of 0-16MPA makes it suitable for testing
a wide range of plastic pipes.
Whether you are in the manufacturing or testing industry, this
Plastic Pipe Hydrostatic Pressure Testing Machine is the perfect
tool for testing the hydrostatic pressure of plastic pipes. Its
safety protection features, certification, accuracy, and testing
range make it an ideal choice for any facility that deals with
plastic pipes such as PPR, PB, and PERT as well as thermoplastic
pipes.
Features:
Product Name: Hydrostatic Pressure & BurstingTesting Machine
Accuracy: -1%~+2%
Test Curve: Pressure-time And Pressure-temperature
Test Temperature Range: 15~95℃
Testing Range: 0-16MPA
Application: Suitable for hydrostatic pressure & bursting testing
of PE PVC PPR PB PERT and other thermoplastics pipes and fittings
Meet Standards:
ISO1167-2006, ASTMD1598-2004, ASTMD1599, ISO9080, CJ/T108,
ASTMF1335.
Technical Parameters:
| Model | XGY-16C |
| Diameter range | Φ8-1800mm |
| Stations | 3, 5, 6, 12, 15, 18, 20, 25, 50, 100 etc can customized |
| Control mode | Micro-control, industrial PC control |
| Display mode | Industrial PC LCD color display |
| Storage mode | PC strorage |
| Print mode | Color printer output |
| Test pressure | Pressure range | 0.1-16MPa |
| Control accuracy | ±1% |
| Display resolution | 0.01MPa |
| Working range | 5%~100%FS |
| Indication error | ±1% |
| Test Timer | Timer range | 0~10000h |
| Timer accuracy | ±0.1% |
| Timer resolution | 1s |
| Power | 380V 50Hz three-phase four-wire 1.5KW |
| end caps models | from Φ8 to 1800mm |
| Water tank size | accoard to the pipe size |
| Temperature range | 15-95℃ |
| Dimensions (three stations) | 715×625×1700(mm)or others |
Support and Services:
Hydrostatic testing machine Plastic Pipe Hydrostatic Pressure
Testing Machine Technical Support and Service
We provide technical support for Hydrostatic Pressure Testing
Machines. Our experienced technical support team can provide:
- Machine installation and setup
- Troubleshooting and technical advice
- Repair and maintenance services
- Spare parts and consumables
- Software updates and upgrades
We are committed to providing excellent customer service and are
available to answer any questions you may have. If you have any
queries, please don't hesitate to contact us.
FAQ:
Q1: What is the brand name of the Hydrostatic testing machine
Plastic Pipe Hydrostatic Pressure Testing Machine ?
A1: The brand name for the Hydrostatic Pressure Testing Machine is
JHH, which is manufactured in Beijing, China.
Q2: What is the purpose of the Hydrostatic testing machine Plastic Pipe Hydrostatic Pressure
Testing Machine?
A2: The Hydrostatic testing machine Plastic Pipe Hydrostatic Pressure
Testing Machine is used to test the hydrostatic and bursting strength of plastic
pipe.
Q3: What type of components and materials can the Hydrostatic
Pressure Testing Machine test?
A3: The Hydrostatic Pressure Testing Machine can be used to test
plastic pipe, composite pipe (like PP-R, PP-B, PP-A, PVC, PE, PE-X
etc.
Q4: What is the accuracy of the Hydrostatic Pressure Testing
Machine?
A4: The Hydrostatic Pressure Testing Machine is accurate to within
0.1% of the full-scale reading.
